The Avigilon Alta A5 Dome Camera is a cloud-managed fixed dome built for fast deployment and reliable indoor or outdoor coverage, pairing on-device processing and storage with the Alta Video platform to minimise on-site infrastructure and simplify ongoing management. It’s available in 5MP 3072×1728 at 30 fps or 8MP 4K 3840×2160 at 30 fps, using a 1/1.8 inch sensor and a motorized 3.6–10 mm lens with remote zoom and focus and P-iris for precise commissioning and sharper depth of field. For challenging lighting it uses multi exposure line based HDR, and for night scenes it includes integrated 850 nm IR with 30 m range, automatic night mode and an IR cut filter. Built in intelligence includes AI video analytics plus AI audio event classification from a 4 microphone array, with audio source localization to help operators quickly identify where an incident is happening. The camera supports H.264 and Motion JPEG, includes 2× microSD storage, and is hardened with factory installed certificates backed by a TPM, no default passwords, mandatory access authentication, and HTTPS TLS encryption, all in a robust IK10 and IP66 aluminum housing rated for -40°C to +50°C operation, with a 10 year warranty with an Alta Video license or 3 year warranty without.
Avigilon Alta A5 Dome Camera
- Crisp video in any light: Choose 5MP or 4K with multi exposure line based HDR plus a motorized 3.6–10mm lens with remote zoom and focus and P iris and 850 nm IR night vision with up to 30 m range
- Cloud native and analytics ready: Built for Alta Video with on camera processing and storage dual microSD and AI video and audio analytics including a 4 microphone array with audio event classification and audio source localization
- Rugged and secure by design: Outdoor ready IP66 and IK10 vandal resistance powered by PoE plus with factory installed certificates backed by TPM no default passwords and mandatory access authentication plus up to 10 year warranty with an Alta Video license
Key Features
Resolution
Avigilon Alta A5 Dome Camera • 8 MP 4K 3840×2160 @ 30 fps • 5 MP 3072×1728 @ 30 fps • Image sensor 8 MP 4K or 5 MP with 1/1.8 inch format • Field of view 100°–45° horizontal and 53°–25° vertical • Minimum illumination in colour 0.15 lux
IR Illumination
IR night vision • Automatic night mode • IR cut filter • 850 nm IR LED • IR range 30 m
Dynamic Range
Multi exposure line based HDR
Artificial Intelligence
Built in AI video analytics • AI audio features including audio event classification and audio source localization
Analytics
Microphone array 4 microphones • On device storage and processing • Storage 2× MicroSD SDXC UHS I • Electronic leveler installation aid • Note SKUs available with onboard retention options 30 days 60 days or 120 days in Alta Video Cloud
Cybersecurity
Factory installed certificates • No default passwords • Mandatory access authentication • HTTPS TLS encryption • ONVIF Profile S when set to ONVIF mode
Casing
IK10 impact resistance • IP66 ingress protection • Aluminium body • Operating temperature -40°C to +50°C • Storage temperature -40°C to +60°C • Dimensions 152×152×96 mm • Weight 1.2 kg • Power source PoE+ 802.3at Type 2 • USB C for installation only preview and setup • Power consumption typical 5 W max 13 W without heater max 23 W with heater
Warranty
10 year warranty with Alta Video license or 3 year warranty without
Avigilon Alta A5 Dome Camera Overview
