Avigilon H4 Video Intercom
- See every visitor clearly, day or night 3MP 170° fisheye with triple-exposure WDR, LightCatcher low-light imaging, and integrated IR for 0-lux scenes.
- Clear two-way communication Full-duplex audio with built-in mic/speaker, plus noise reduction and echo cancellation for intelligible conversations at the door.
- Stronger entry control with simpler installs Single PoE connection with I/O for door locks, remote door grant via ACC / ACC Mobile / ACM, plus SIP calling support and a rugged IK10 / IP66 housing with tamper detection.
Key Features
Resolution
3MP max 2048×1536 (4:3). Other supported streams: 1920×1080, 1280×960, 1280×720, 640×480. Lens / view: fisheye with 170° horizontal field of view. Max frame rate: up to 30 fps (50/60 Hz). Compression: H.264 and Motion JPEG with HDSM SmartCodec™.
IR Illumination
Integrated IR LEDs for 0-lux scenes. IR range: up to 5 m (16 ft). Automatic day/night with IR-cut filter.
Dynamic Range
WDR: Triple-exposure WDR (with dual-exposure WDR at full frame rate).
Artificial Intelligence
Optimised for entry workflows within the Avigilon Unity ecosystem; supports system-level capabilities such as Appearance Search™ and Facial Recognition when enabled/licensed in the wider solution (not an edge-AI classification camera).
Analytics
Tamper detection (physical tamper).
Video motion capabilities via VMS rules/workflows; intercom events support door/entry automation in supported Unity platforms.
Cybersecurity
HTTPS encryption, 802.1X network authentication, digest authentication, user access controls and logs.
Supports secure device communications and enterprise deployment policies.
Casing
Outdoor-ready: IP66 ingress protection. Impact: IK10 enclosure / IK08 bubble. Mounting: recessed or surface-mount housings; tamper-resistant design suitable for exposed entry points.
Warranty
5-year limited warranty (standard Avigilon Unity camera warranty terms).
Avigilon H4 Video Intercom Overview
The Avigilon H4 Video Intercom combines a 3MP fisheye camera (170° horizontal view) with a high-performance intercom to create a single, secured entry-point device that helps teams see, speak with, and authorise visitors before granting access. It’s engineered for difficult lighting with LightCatcher™ low-light performance, triple-exposure Wide Dynamic Range (and dual-exposure WDR at full frame rate), plus integrated IR LEDs for 0-lux scenes (up to 5 m). Two-way communication is clear and natural with full-duplex audio, noise reduction, and echo cancellation, supporting Opus and G.711 codecs, and it also supports SIP for peer-to-peer and PBX voice-only calling. For practical door control, it provides digital I/O for interfacing with locks and other equipment, PoE (802.3af Class 3) single-cable networking/power, and microSD support for onboard storage. It’s built for exposed entry points with tamper-resistant recessed or surface-mount housings, physical tamper detection, IP66 weather protection, and IK10 impact rating on the enclosure (IK08 on the bubble), and includes enterprise-ready features like H.264/MJPEG with HDSM SmartCodec™, ONVIF Profiles S and G, and cybersecurity controls including HTTPS encryption and 802.1X—with support for advanced Unity workflows such as Appearance Search™ and Facial Recognition where the broader system is licensed and configured.
