Avigilon H5A IR PTZ Camera
- Powerful IR for true night detail Built-in IR reaches up to 300 m (2MP) or 150 m (4MP/8MP) and adapts to zoom.
- Fast PTZ with long-range zoom 360° endless pan, look-up tilt, and up to 40× (2MP) / 36× (4MP/8MP) optical zoom.
- Smarter alerts, rugged outdoors AI analytics + auto-tracking, efficient H.265 SmartCodec, and tough IP/IK/NEMA ratings.
Key Features
Resolution
2MP: 1937×1097 active pixels; up to 60 fps; 1/2.8” progressive scan CMOS; 40× optical zoom; 4.25–170 mm (F/1.6–4.95) autofocus; 66.35°–1.9° horizontal AoV. 4MP: 2688×1512 active pixels; up to 30 fps; 1/2.5” Exmor R CMOS; 36× optical (or 30× with image stabilization on); 4.4–88 mm (F/2.0–3.8) autofocus; 69.7°–2.2° horizontal AoV. 8MP / 4K: 3840×2160 active pixels; up to 30 fps; 1/2.5” Exmor R CMOS; 36× optical (or 30× with image stabilization on); 4.4–88 mm (F/2.0–3.8) autofocus; 69.7°–2.2° horizontal AoV. PTZ performance (all):360° continuous pan + -20° to 90° tilt (“look-up” above horizon) at up to 300°/sec; 500 named presets; 10 named tours; up to 64 3D privacy zones; up to 100× digital zoom when used with ACC Client (Windows).
IR Illumination
Automated IR with projection angle that adjusts to zoom level and field of view for consistent scene illumination. IR range: 300 m (2MP); 150 m (4MP/8MP). Minimum illumination: 0 lux in IR mode; 2MP: 0.03 lux (colour), 0.02 lux (mono). 4MP/8MP: 0.3 lux (colour), 0.09 lux (mono).
Dynamic Range
2MP: 120 dB dynamic range. 4MP/8MP: 100 dB dynamic range. Additional image controls: 3D noise reduction, digital defog (adjustable/off), backlight compensation on/off, automatic/manual shutter and white balance.
Artificial Intelligence
Next-Generation Video Analytics with Auto-Tracking designed for expanded object classifications and faster response, with the camera able to automatically track objects in zone (system configuration dependent).
Analytics
Analytics at home position with classified object detection alongside pixel motion detection. Auto-tracking configuration requirement: requires ACC 7.14.14+ to configure.
Supported analytic events include: Objects in Area, Object Loitering, Objects Crossing Beam, Object Appears/Enters Area, Object Not Present in Area, Objects Enter Area, Objects Leave Area, Object Stops in Area, Direction Violated.
Cybersecurity
Password protection, HTTPS encryption, digest authentication, WS authentication, user access log, 802.1X port-based authentication. FIPS options: FIPS 140-2 Level 1 (optional camera license) + onboard FIPS 140-2 Level 3 certified TPM for key protection. Firmware integrity: signed and encrypted firmware. Interoperability: ONVIF Profiles S, T, and G (Profile G supports edge recording search/playback/retrieval).
Casing
Built for harsh outdoor sites: NEMA Type 4X, IP66/IP67/IP68, IK10 (enclosure), and NEMA TS2 environmental suitability (traffic applications). Integrated wiper across options; pendant mount housing. Environmental: -40°C to +60°C continuous operation; sustained wind 241 kph (150 mph); humidity 5–95% non-condensing. Physical: Ø250 mm × 364 mm, 6.76 kg; body aluminum + polycarbonate with optical glass front window.
Warranty
5-year limited warranty (extended warranty not available for this PTZ line).
Avigilon H5A IR PTZ Camera Overview
The Avigilon H5A IR PTZ range (available in 2MP, 4MP and 8MP) is built for large, high-risk outdoor sites where you need fast situational awareness by day and confident identification at night—without relying on external lighting. It combines 360° continuous pan with -20° to 90° tilt (including a 20° “look-up” above the horizon) and high-speed movement up to 300°/second, paired with long-range optics (40× zoom on 2MP; 36× on 4MP/8MP) for rapid wide-to-tele control. For night performance, its automated IR maintains consistent illumination by adjusting to zoom and field of view, delivering up to 300 m IR range on 2MP and 150 m on 4MP/8MP, with 0 lux operation in IR mode. Embedded Next-Generation Video Analytics with auto-tracking helps detect and follow targets automatically, while H.264/H.265 with HDSM SmartCodec™ reduces bandwidth and storage load. It’s hardened for harsh environments with Type 4X, IP66/67/68, IK10, and NEMA TS2 compliance, and includes enterprise-ready features like ONVIF Profiles S/T/G, onboard microSD storage, optional FIPS 140-2 Level 1 license, and an onboard FIPS 140-2 Level 3 TPM for stronger key protection.
