Avigilon H6A Dual Head Camera
- Two views, one install: Dual heads cover both directions in corridors, stairwells and corners—one camera, one cable run, fewer devices.
- Dial-in coverage, day or night: Options up to 16 MP total, varifocal lenses with remote zoom/focus + autofocus, and 850 nm IR for low-light scenes.
- Unity or Alta deployment: Unity H6A Dual Head suits on-prem Unity/ACC with AI analytics and strong device security; Alta H6A Dual Head adds cloud access, real-time alerts and smart search for multi-site management.
Key Features
Resolution
Avigilon Unity H6A Dual Head Camera • Total resolution options: 6 MP / 10 MP / 16 MP (2×3 MP / 2×5 MP / 2×8 MP) • Two independently aimed imaging heads for bidirectional coverage • Image sensors: progressive scan CMOS (per-head sensor size varies by model) • Multi-stream video • Compression: H.264 + H.265 with HDSM SmartCodec™ + Motion JPEG • Bandwidth tools: Idle Scene Mode and smart bitrate control (HDSM SmartCodec™) Avigilon Alta H6A Dual Head Camera • Total resolution options: 6 MP / 10 MP / 16 MP (2×3 MP / 2×5 MP / 2×8 MP) • Two independently aimed imaging heads • Multi-stream video • Compression: H.264 (cloud-managed streaming)
IR Illumination
Unity H6A Dual Head • Built-in 850 nm IR on IR models • Automatic day/night • IR cut filter • IR range up to 30 m (model dependent) Alta H6A Dual Head • Built-in 850 nm IR on IR models • Automatic day/night • IR cut filter • IR range up to 30 m (model dependent)
Dynamic Range
Unity H6A Dual Head • True WDR up to 120 dB (model dependent) • Designed to maintain usable detail in backlit corridors, doorways and mixed lighting Alta H6A Dual Head • True WDR up to 120 dB (model dependent)
Artificial Intelligence
Unity H6A Dual Head • AI video analytics for proactive detection and faster review (people/vehicle classification where supported by the analytics mode) • Supports rules such as area/line events, loitering and direction violations to reduce “motion-only” noise Alta H6A Dual Head • Cloud analytics + Smart Search workflows for rapid investigations across sites • Real-time rules for people/vehicle activity and behaviour-based events (rule availability depends on licensing/configuration)
Analytics
Unity H6A Dual Head • Two heads can run analytics simultaneously for bidirectional detection • Typical analytic events include: Objects in Area, Line/Beam Crossing, Loitering, Direction Violations, Tamper Detection (event set depends on configuration) • Edge resilience: dual microSD slots for onboard/edge recording (recommended high-endurance media) Alta H6A Dual Head • Cloud-managed events and search tools including Smart Search, plus operational insights like occupancy counting and people-flow heatmaps (features depend on licensing/configuration)
Cybersecurity
Unity H6A Dual Head • Enterprise hardening: HTTPS encryption, 802.1X, role-based authentication • Device integrity: Secure Boot, signed/encrypted firmware • Hardware trust: onboard TPM (FIPS-grade design) to protect keys and device identity Alta H6A Dual Head • Cloud-managed security model with encrypted communications and controlled authentication • Designed for fleet management with automatic firmware updates and consistent security posture across multi-site deployments
Casing
Unity H6A Dual Head • Dual-head housing designed for corridor/corner/stairwell coverage • Adjustable heads for precise aiming during commissioning • Outdoor-capable variants are built for harsh sites with rugged impact/weather protection (rating varies by model/variant) • Power: PoE+ (802.3at) commonly used for full feature sets (heater/IR and configuration dependent) Alta H6A Dual Head • Matching dual-head form factor for cloud deployments • Rugged outdoor variants available (rating varies by model/variant) • Power: PoE+ (802.3at) (feature/variant dependent)
Warranty
Unity H6A Dual Head • 5-year warranty Alta H6A Dual Head • Limited 10-year warranty (license/region terms apply)
Avigilon Unity & Alta H6A Dual Head Camera Overview
The Avigilon H6A Dual Head range is designed to eliminate blind spots in corridors, stairwells, corners and narrow walkways by combining two independently aimed sensors in a single camera, cutting down on hardware, cable runs and licensing compared with installing two separate cameras. The line is available in 6 MP, 10 MP and 16 MP total configurations (2×3 MP, 2×5 MP, 2×8 MP) using 1/2.8″ progressive-scan CMOS sensors, with varifocal 3.24–7.33 mm lenses per head and remote zoom/focus plus autofocus so you can precisely frame both directions during commissioning. For consistent performance day and night, it includes True WDR up to 120 dB, LightCatcher™ low-light optimisation, and built-in 850 nm IR with an up to 30 m range. On the Unity side, the camera supports efficient streaming and evidence capture with HDSM SmartCodec™ + idle scene mode, multi-stream H.264/H.265 (plus Motion JPEG), two microSD slots for edge storage, and a built-in microphone (with a physical disable switch) to support audio analytics and optional audio recording—all reinforced by enterprise hardening such as 802.1X, Secure Boot, signed/encrypted firmware, and an onboard FIPS 140-2 Level 3 certified TPM. On the Alta side, the same dual-head hardware becomes a cloud-native solution for multi-site visibility, pairing real-time analytics with workflow tools like Smart Search, occupancy counting and people-flow heatmaps, plus automatic firmware updates, NDAA 2019 Section 889 compliance, and a limited 10-year warranty—while remaining rugged for harsh environments with IP66/67/68, IPX9K, IK10 and NEMA 4X protection and operation down to -40°C with PoE+.
