Avigilon H6A/H6X Bullet Camera
- See far, even in total darkness: Bullet form factors with 2 MP / 4 MP / 6 MP / 8 MP (4K) options, True WDR up to 150 dB (mode dependent), and built-in 850 nm IR for long-range night detail—up to 50 m, 70 m, or 170 m at full-tele (lens/variant dependent).
- Smarter alerts, faster investigations: AI video analytics with classified object detection (people + vehicles, including vehicle sub-types in outdoor mode), plus advanced event rules (e.g., area/line crossing/loitering and unusual crowd size). Add dual microSD slots for edge recording and efficiency features like HDSM SmartCodec™ + idle scene mode, EIS, and Corridor Mode.
- Built for compliance and harsh sites: Enterprise hardening including FIPS 140-2 Level 3 TPM, Secure Boot, and signed/encrypted firmware, plus rugged outdoor ratings (IK10/IK11, IP66/67/68, NEMA Type 4X). Choose H6A for audio analytics via built-in mic (select variants, with a physical disable switch), or H6X for privacy/cyber requirements with no built-in microphone or wireless, and Gigabit Ethernet (H6X).
Key Features
Resolution
Avigilon H6A / H6X Bullet Cameras • Models: 2.0 MP / 4.0 MP / 6.0 MP / 8.0 MP (4K Ultra HD) • Image sensors: 2 MP = 1/2.8″ progressive scan CMOS; 4/6/8 MP = 1/1.8″ progressive scan CMOS • Max primary resolution: 2 MP 1920×1080 (16:9) • 4 MP 2688×1520 (16:9) / 1984×1488 (4:3) • 6 MP 3328×1872 (16:9) / 2880×2160 (4:3) • 8 MP 3840×2160 (16:9) / 2880×2160 (4:3) • Streams: Primary + Secondary + Tertiary (multi-stream) • Max image rate: 2 MP & 4 MP up to 50/60 fps in High Frame Rate Mode (analytics disabled), otherwise 25/30 fps • 6 MP & 8 MP up to 25/30 fps • Bandwidth tools: HDSM SmartCodec™ + Idle Scene Mode • SNR: > 50 dB • Compression: H.264 HDSM SmartCodec™ / H.265 HDSM SmartCodec™ / Motion JPEG
IR Illumination
Built-in IR (high-power 850 nm LEDs) • IR range depends on lens/variant: Short bullet 2.8–12 mm: 50 m full-tele / 30 m full-wide • Short bullet 4.4–9.3 mm: 70 m full-tele / 40 m full-wide • Long bullet: up to 170 m full-tele / 40 m full-wide • Day/Night: Automatic / Manual / External • Controls: Remote zoom & focus, autofocus, IR cut filter • IR output can reduce at temperature extremes (automatic IR management).
Dynamic Range
True WDR/HDR • WDR Off: Up to 83 dB • WDR On (model/mode dependent): 2 MP up to 150 dB (dual/triple exposure depending on frame rate) • 4 MP up to 144 dB (dual/triple exposure depending on frame rate) • 6 MP up to 144 dB (dual exposure, ≤20 fps) • 8 MP up to 150 dB (triple exposure, ≤20 fps).
Artificial Intelligence
AdaptAI video analytics (H6A + H6X) • Classified object detection: Indoor mode = Person • Outdoor mode = Person + Vehicle sub-types (Car, Pickup Truck, Large Truck, Van, Bicycle, Motorcycle, Bus) • Teach-By-Example: supported when used with Avigilon Control Center™ or Avigilon Unity Video • Crowd analytics events supported (crowd size, unusual crowd growth, unusual crowd size) • H6A only (select variants): audio analytics + optional audio recording via built-in microphone with a physical disable switch.
Analytics
Supported analytics events include: Objects in Area (incl. counting) • Object Loitering • Objects Crossing Beam (uni/bi-directional) • Object Appears/Enters Area • Object Not Present in Area • Objects Enter Area (threshold) • Objects Leave Area (threshold) • Object Stops in Area • Object Too Close • Direction Violated • Smart Motion Rule • Tamper Detection • Crowd Size / Unusual Crowd Growth / Unusual Crowd Size • Motion detection: Pixel motion (selectable sensitivity/threshold) + classified object detection • Privacy: Up to 64 privacy zones • Stabilisation: Electronic Image Stabilization (EIS) • Corridor Mode: 0°/90°/180°/270° rotation • Edge recording: Dual microSD slots (Class V10 or better recommended; tested up to 1.5 TB) • Note: Max frame rate is 15 fps when classified object privacy masking is enabled; High Frame Rate Mode disables analytics.
Cybersecurity
Enterprise hardening (H6A + H6X) • Security: Password protection, HTTPS encryption, Digest + WS authentication, user access log, 802.1X • Crypto: FIPS 140-2 Level 1 (with optional camera license) + onboard FIPS 140-2 Level 3 certified TPM • Platform integrity: Secure Boot + signed/encrypted firmware • Standards & interoperability: ONVIF Profiles S / T / M / G • Secure streaming options include SRTP • Protocol support includes HSTS, QoS, DSCP • Network: H6A = 100BASE-TX • H6X = 1000BASE-T (Gigabit) • Compliance design: H6X is designed with no built-in microphone and no wireless technology (privacy/cyber requirements).
Casing
Outdoor-ready bullet platforms (Short + Long form factors) • Impact / ingress (variant dependent): IK10 (and IK11 on select variants) • Weather/harsh-site ratings: IP66 / IP67 / IP68 (1.8 m depth for 2 hours) + IPX9K + NEMA 4X • Operating temp: -50°C to +65°C • Startup temp: -40°C to +65°C • Humidity: 0–100% non-condensing • Body: Polycarbonate + aluminum • Finish: high-polished plastic injection mold; powdercoat grey (Pantone 427C) • Adjustment range: Hinge ±90°; Rotation ±175° • Dimensions (L×W×H): Short 311×133×133 mm • Long 407×137×138 mm • Weight: Short 2.11 kg • Long 2.92 kg (wall plate 0.15 kg) • Power: 25 W max • PoE (802.3af Class 3) / PoE+ (802.3at Class 4) • External power 12–24 VDC ±10% • H6X only: redundant power with seamless failover between PoE and auxiliary without interrupting operation.
Warranty
Limited 5-year warranty
Avigilon H6A & H6X Bullet Cameras Overview
Avigilon H6A/H6X Bullet Cameras are built for long-range outdoor coverage with two form factors—short bullet for wide-to-mid scenes and long bullet for high-zoom perimeter and roadway views—across 2 MP, 4 MP, 6 MP and 8 MP (4K) options. They pair remote zoom/focus varifocal optics (including long-zoom lens options) with built-in high-power 850 nm IR, delivering night visibility from 30–70 m on standard bullets and up to 170 m (full-tele) on long-zoom variants (lens dependent). Wide dynamic range performance scales by model and mode, reaching up to 150 dB in triple-exposure HDR for demanding scenes like headlights, gates and reflective signage, while efficiency features such as H.264/H.265 HDSM SmartCodec™ and idle scene mode reduce storage and bandwidth without sacrificing usable evidence. Both lines include AI video analytics with classified objects (people and vehicles, including vehicle sub-types in outdoor mode), plus advanced events like loitering, line/beam crossing, direction violations and unusual crowd size, with Teach-By-Example supported when used with Avigilon Unity/ACC. Choose H6A when you want audio analytics (built-in mic on certain variants with a physical disable switch), or H6X when you need stricter privacy/cyber compliance (no built-in mic or wireless) and Gigabit Ethernet; both are hardened with Secure Boot, signed/encrypted firmware, and an onboard FIPS 140-2 Level 3 TPM, with dual microSD slots (tested up to 1.5 TB) and rugged outdoor protection including IP66/67/68, IPX9K, NEMA 4X and IK10.
