AXIS A4612 Network Bluetooth Reader

Bluetooth 5.0 and 13.56 MHz RFID reader in a slim mullion-mount form factor. Mobile or card access, full door control over one PoE cable, IP55-rated indoors and outdoors.

Phone or Card — Your Choice of Access The A4612 supports Bluetooth mobile credentials via the AXIS Mobile Credential app — users can tap in the app, or simply tap the reader itself with their phone in their pocket — alongside 13.56 MHz RFID cards including MIFARE Classic, MIFARE Plus, and MIFARE DESFire EV1, EV2, and EV3.
Complete Door Control Over a Single PoE Cable One device manages the full door — including the door lock and door position sensors — with PoE eliminating the need to wire back to a door controller. Bluetooth range is configurable up to 3 m for short range and up to 10 m for long range.
Slim Mullion-Mount Design for Any Environment A mullion-mount form factor with a scratch-resistant glass front panel makes the A4612 ideal for tight spaces and door frame installations, with IP55 rating for reliable use both indoors and outdoors. Backed by a 5-year warranty.

smartphone

Mobile Credential Access

Tap the reader or keep your phone in your pocket — the AXIS Mobile Credential app handles entry seamlessly.

credit_card

13.56 MHz RFID Card Support

Compatible with MIFARE Classic, MIFARE Plus, and MIFARE DESFire EV1, EV2, and EV3 card standards.

power

Full Door Control Over One PoE Cable

Manages door lock and position sensors from a single network cable — no separate power supply or door controller wiring needed.

straighten

Slim Mullion-Mount for Tight Spaces

A compact, scratch-resistant glass-fronted design built for door frames, narrow walls, and space-constrained installations.

AXIS A4612 Overview:

The AXIS A4612 is a slim mullion-mount reader supporting Bluetooth 5.0 Low Energy mobile credentials via the AXIS Mobile Credential app and 13.56 MHz RFID cards — including MIFARE Classic, MIFARE Plus, and MIFARE DESFire EV1, EV2, and EV3. Bluetooth range is configurable between 3 m and 10 m, with RSA-1024 and AES-128 encryption securing all communication. As a complete single-door IP interface, it manages door lock control, door position monitoring, and REX input via two digital inputs and one relay — all over a single PoE IEEE 802.3af cable, eliminating the need to wire back to a separate door controller. A built-in tamper switch, RGB LED, and audible buzzer are included, and the IP55-rated scratch-resistant glass-front casing operates from –40°C to +60°C for indoor and outdoor use. Backed by a 5-year warranty.
