The AXIS M30 Dome Camera Series is a compact, cost-effective range of mini domes designed to deliver strong performance without complexity—spanning fixed-lens models up to 8 MP (including AXIS M3085-V, M3086-V and M3088-V) and 360° panoramic options like AXIS M3057-PLR Mk II and the outdoor-ready AXIS M3077-PLVE for full-room coverage with a single camera. Across the range you get Wide Dynamic Range (WDR) plus Lightfinder and/or day/night functionality for clear detail in tricky lighting, and factory focus to speed up commissioning. Built-in deep learning processing (DLPU) enables on-camera analytics such as AXIS Object Analytics (object detection/classification and insights like loitering), with optional expansion for audio and I/O via the AXIS T61 Series. For efficiency and resilience, Axis Zipstream helps cut bandwidth/storage, selected models support H.264/H.265 with edge storage, and Axis Edge Vault adds hardware-based cybersecurity protection from day one.
AXIS M30 Dome Camera Series
- Discreet dome design, tough where it counts: Compact indoor/outdoor-ready domes that blend into the space while delivering dependable, day-to-day surveillance.
- Clear evidence, less bandwidth: Sharp image quality with smart compression to keep storage and network costs down—without sacrificing detail.
- Fast to install, simple to run: Flexible mounting options and easy configuration help you get coverage up quickly, with reliable performance and low maintenance.
Key Features
Resolution
AXIS M3057-PLVE Mk II 6 MP panoramic 2016×2016 with multiple dewarped views available | AXIS M3077-PLVE 6 MP panoramic 2016×2016 with multiple dewarped views available | AXIS M3085-V 2 MP Full HD class | AXIS M3086-V and AXIS M3086-V Mic 4 MP 2688×1512 | AXIS M3088-V 8 MP 4K 3840×2160 With Forensic WDR AXIS M3057-PLVE Mk II and AXIS M3077-PLVE up to 25/30 fps | No WDR 360° overview only AXIS M3057-PLVE Mk II and AXIS M3077-PLVE up to 50/60 fps | Frame rate fixed domes AXIS M3086-V up to 25/30 fps | AXIS M3088-V up to 12/15 fps
IR Illumination
AXIS M3057-PLVE Mk II and AXIS M3077-PLVE OptimizedIR with power efficient long life 850 nm IR LEDs typical reach around 20 m scene dependent | AXIS M3085-V AXIS M3086-V AXIS M3086-V Mic AXIS M3088-V no built in IR typically paired with external lighting where needed
Dynamic Range
AXIS M3057-PLVE Mk II and AXIS M3077-PLVE Forensic WDR up to 120 dB scene dependent | AXIS M3085-V AXIS M3086-V AXIS M3086-V Mic AXIS M3088-V WDR up to 120 dB scene dependent
Artificial Intelligence
AXIS M3085-V AXIS M3086-V AXIS M3086-V Mic AXIS M3088-V deep learning processing unit DLPU enabling deep learning analytics at the edge
AXIS M3057-PLVE Mk II and AXIS M3077-PLVE designed to support on camera analytics and ACAP apps rather than the DLPU Object Analytics mini dome platform positioning
Analytics
AXIS M3057-PLVE Mk II: AXIS Video Motion Detection Motion Guard Fence Guard Loitering Guard active tampering alarm supports additional apps via ACAP
AXIS M3077-PLVE: same core analytics includes audio detection and built in microphone can be disabled
AXIS M3085-V: AXIS Object Analytics AXIS Scene Metadata AXIS Live Privacy Shield AXIS Video Motion Detection
AXIS M3086-V and AXIS M3086-V Mic: AXIS Object Analytics AXIS Scene Metadata AXIS Live Privacy Shield AXIS Video Motion Detection Mic variant ready for AXIS Audio Analytics object detection classification includes humans and vehicles cars buses trucks bikes
AXIS M3088-V: AXIS Object Analytics AXIS Scene Metadata AXIS Live Privacy Shield AXIS Video Motion Detection humans and vehicles classification plus time in area style insight features
Cybersecurity
AXIS M3057-PLVE Mk II and AXIS M3077-PLVE: Axis device ID signed firmware OS secure boot hardware backed security Axis Edge Vault
AXIS M3085-V, AXIS M3086-V, AXIS M3086-V Mic, AXIS M3088-V: Axis device ID signed OS secure boot secure keystore signed video hardware backed security Axis Edge Vault
Casing
AXIS M3057-PLVE Mk II and AXIS M3077-PLVE: outdoor ready housings IP66 NEMA 4X IK10 class protection polycarbonate dome robust body construction | AXIS M3085-V, AXIS M3086-V, AXIS M3086-V Mic, AXIS M3088-V: indoor rated mini dome housings IP42 IK08 class protection
Warranty
5 year warranty
Compact Domes, Powerful Coverage
AXIS M30 Series Datasheets
