The AXIS V59 PTZ Camera Series is built for broadcast-quality live streaming and AV integration in spaces like auditoriums, classrooms, and places of worship, combining smooth pan tilt zoom control, professional audio options, and direct outputs for production workflows. The current range includes AXIS V5925 PTZ Camera and AXIS V5938 PTZ Network Camera, giving you a choice between HDTV 1080p at up to 60 fps with 30x optical zoom (V5925) and UHD 4K at up to 30 fps with 20x optical zoom (V5938) for higher detail capture. Both models are designed to drop into pro environments with 3G SDI and HDMI outputs, VISCA via RS 232, and VISCA over IP for multi camera control, while also supporting efficient IP streaming with Axis Zipstream using H 264 and H 265 to reduce bandwidth and storage without sacrificing quality. For clean, production-ready sound, both support balanced XLR inputs with 48 V phantom power plus 3.5 mm audio in out, enabling studio microphones and flexible audio routing, and they include a 3 month CamStreamer trial for simple platform streaming as well as NDI compliance with license purchased separately for modern IP-based production. Finally, they include security hardening such as signed firmware and secure boot to help protect integrity in connected AV and enterprise networks.
AXIS V59 PTZ Camera Series
- Broadcast-ready PTZ video: Smooth pan tilt zoom for professional live production and hybrid events with high-quality imaging and strong zoom capability
- AV integration made easy: Flexible connectivity and control options depending on model including outputs for professional workflows plus IP streaming for remote production and monitoring
- Smart operation and reliability: Presets and touring for fast scene changes with efficient compression to reduce bandwidth and Axis-grade cybersecurity for safer deployments
Key Features
Resolution
AXIS V5925 PTZ Camera 1920×1080 HDTV 1080p to 160×90 • Up to 60/50 fps 60/50 Hz in all resolutions • 30x optical zoom plus 12x digital total 360x • HDMI SDI output 1080p at 50/60 fps 50/60 Hz • Progressive scan RGB CMOS 1/2.8” • Lens 4.4–132 mm F1.4–4.6 with autofocus and P iris • Horizontal field of view 62°–2.3° • Vertical field of view 37°–1.3° • Pan ±170° • Tilt -20° to 90° • 256 preset positions • 3G SDI and HDMI outputs • Axis Zipstream with H 264 and H 265 • NDI compliant license purchased separately • CamStreamer 3 month trial included AXIS V5938 PTZ Network Camera 3840×2160 HDTV 2160p 4K to 160×90 • Up to 30/25 fps 60/50 Hz in 4K and up to 60/50 fps 60/50 Hz in other resolutions • 20x optical zoom plus 12x digital total 240x • HDMI output up to 2160p at 25/30 fps and SDI output up to 1080p at 25/30/50/60 fps • Progressive scan RGB CMOS 1/2.5” • Lens 4.4–88 mm F2.0–3.8 with autofocus and P iris • Horizontal field of view 70.2°–4.1° • Vertical field of view 39.5°–2.3° • Pan ±170° • Tilt -20° to 90° • 256 preset positions • 3G SDI and HDMI outputs • Axis Zipstream with H 264 and H 265 • NDI compliant license purchased separately • CamStreamer 3 month trial included
IR Illumination
No built in IR illumination • Day and night with automatically removable infrared cut filter on both models
Dynamic Range
V5925 Dynamic range not specified in the datasheet • Image controls include exposure zones and defogging V5938 WDR dynamic contrast with highlight compensation plus backlight compensation • Defogging and electronic image stabilization
Artificial Intelligence
V5925 ARTPEC 7 system on chip • 1 GB RAM 512 MB flash V5938 ARTPEC 7 system on chip • 2 GB RAM 512 MB flash
Analytics
Included AXIS Video Motion Detection and AXIS PTZ Autotracking • Support for AXIS Camera Application Platform ACAP for third party apps on both models
Cybersecurity
Signed OS • Secure boot • Brute force delay protection • Digest authentication • OAuth 2.0 • Password protection • SD card encryption AES XTS Plain64 256 bit • Network security includes IEEE 802.1X IEEE 802.1AE MACsec HTTPS HSTS TLS v1.2 v1.3 Network Time Security X.509 Certificate PKI and host based firewall
Casing
Indoor casing with ASA plastic cover • Color White NCS S 1002-B • Operating conditions 0 °C to 40 °C • Storage conditions -40 °C to 65 °C • V5925 network RJ45 10BASE-T 100BASE-TX and terminal block for 2 configurable alarm I O • Typical 14 W max 25 W 11–13 V DC with 12 V power supply included V5938 network RJ45 10BASE-T 100BASE-TX 1000BASE-T and terminal block for 1 alarm input and 1 output • Typical 17.5 W max 20 W 11–13 V DC with 12 V power supply included
Warranty
5 year warranty service for eligible Axis devices shipped from Axis to the original purchaser on or after 1 April 2020
AXIS V59 PTZ Camera Series for Professional Live Production
AXIS V59 Series Datasheets
