Explore the ExCam XF Q1785 with 32x zoom, HDTV 1080p video and explosion protection for hazardous areas.

Powerful long-range detail Capture clear footage from a safer distance with 32x optical zoom, HDTV 1080p, and up to 50/60 fps for smooth, detailed monitoring.
Built for hazardous environments Designed for Zone 1/2/21/22 areas, this explosion-protected camera combines a 316L stainless-steel housing, IP68 protection, and operation from -60°C to 60°C.
Easier to deploy, clearer in tough conditions PoE helps simplify installation, while Lightfinder, Forensic WDR, and electronic image stabilization deliver more usable video in low light, high contrast, and vibration-prone sites.

zoom_in

32x Long-Range Zoom

shield

Explosion-Protected Design

night_sight_max

Clear Vision in Difficult Light

vibration

Stable Video in Harsh Conditions

Key Features

Resolution

2 MP (HDTV 1080p) • Max 1920×1080 (16:9) down to 160×120 (4:3) • Frame rate: up to 50/60 fps (50/60 Hz) with WDR off, or up to 25/30 fps (50/60 Hz) with Forensic WDR enabled

IR Illumination

No built-in IR illumination is listed in the current Axis datasheet • Low-light performance instead relies on Lightfinder with minimum illumination of 0.16 lux (colour) and 0.03 lux (B/W) at 50 IRE, F1.4

Dynamic Range

Forensic WDR up to 120 dB (scene-dependent) for improved detail in high-contrast scenes • Also includes defogging, electronic image stabilization, and barrel distortion correction

Artificial Intelligence

ARTPEC-6 SoC • The current Axis datasheet does not list a dedicated DLPU or built-in deep-learning object classification engine for this model • Supports AXIS Camera Application Platform (ACAP) for additional edge applications

Analytics

Preinstalled: AXIS Motion Guard, AXIS Fence Guard, AXIS Loitering Guard, AXIS Video Motion Detection, active tampering alarm, gatekeeper

Supported: AXIS Perimeter Defender • ACAP support for third-party analytics and application expansion

Cybersecurity

Signed OS, brute force delay protection, digest authentication, OAuth 2.0 (RFC 6749 OpenID Authorization Code Flow), password protection • Storage protection: SD card encryption (AES-XTS-Plain64 256-bit) • Network security: IEEE 802.1X, IEEE 802.1AE (MACsec), HTTPS/HSTS, TLS v1.2/v1.3, NTS, X.509 PKI, host-based firewall

Casing

Explosion-protected industrial housing: ASTM 316L (EN 1.4404) stainless steel for maximum corrosion protection • Environmental rating IP68 • Wiper included • De-icing control • Certified for ATEX, IECEx, EAC Ex, INMETRO, IA, and UKCA hazardous areas including Zones 1, 2, 21, and 22 and Groups IIC and IIIC

Warranty

5-year warranty

Long-Range Protection for Hazardous Areas

The ExCam XF Q1785 is a high-performance fixed explosion-protected network camera built for long-range surveillance in demanding industrial sites, combining a 1/2.8-inch sensor, HDTV 1080p resolution at up to 50/60 fps, and a 32x optical zoom with a 4.3–137 mm lens so operators can capture fine detail from a safer stand-off distance. It is certified for hazardous Zones 1, 2, 21 and 22, with ATEX, IECEx, EAC Ex, INMETRO, IA, and UKCA approvals, and it uses an IP68-rated ASTM 316L stainless-steel housing with an included wiper and operating range of -60°C to 60°C for harsh onshore, offshore, marine, and heavy industrial environments. For image quality, it combines Lightfinder, Forensic WDR up to 120 dB, electronic image stabilization, defogging, and barrel distortion correction to maintain more usable footage in low light, high-contrast scenes, and vibration-prone locations. Practical deployment is also a strength, with PoE, a pre-installed 128 GB microSDXC card, NAS recording support, and built-in analytics including AXIS Motion Guard, Fence Guard, Loitering Guard, AXIS Video Motion Detection, active tampering alarm, and gatekeeper helping streamline installation, recording, and day-to-day monitoring.
